2010 Claas Arion 610 C – Strong 4WD Tractor in the 120-HP Class
The **Claas Arion 610 C** is a dependable 4-wheel drive tractor built for general farm work, loader use, towing, and PTO tasks. With a gross engine rating of ~123 HP (≈ 92 kW) and net power ~114 HP (≈ 85 kW), this model performs well in field, road and yard work. Equipped with 16 forward / 16 reverse gears via a powershift or partial-power shift transmission, speed up to **40 km/h**, and approximately 5.7-ton operating weight, it’s a strong fit for mid-sized operations.
Key Specifications.
2010 Claas Arion 610 C – Strong 4WD
- Engine & Power: Gross ~123 HP / 92 kW; Net ~114 HP / 85 kW. (Claas Arion 610 C, 2007-2013).
- Transmission: 16 forward × 16 reverse; powershift with shuttle control.
- Drive Type: Four-wheel drive (4WD) with power steering.
- Hydraulic System: Load-sensing hydraulics; pump flow ≈ 110.1 L/min.
- PTO Options: Rear PTO 540 / 1000 rpm; optional economy PTO (“E”) speeds.
- Operating Weight: ~5,719 kg.
- Dimensions: Wheelbase ~281 cm; transport length ~5.16 m; height ~2.99 m.
- Top Speed: ~40 km/h.
- Tires (Standard): Front ~14.9R28; Rear ~18.4R38.
Why It’s a Practical Choice.
2010 Claas Arion 610 C – Strong 4WD
- Balanced power for a wide range of tasks—loader, PTO, drawbar—without moving into overly large, high-maintenance machines.
- 4WD gives good traction in varied field conditions.
- Powershift transmission and shuttle control ease loader and yard work (frequent forwards/reverse use).
- Hydraulic flow is generous for its class, allowing multiple rear remotes and responsive hitch / implement work.
- Reasonable dimensions and weight makes it easier to transport, maneuver and maintain.
Best Applications & Use Cases.
2010 Claas Arion 610 C – Strong 4WD
- Loader work—feeding, silage, material handling.
- PTO work—mowers, balers, sprayers etc. that require 540/1000 rpm PTO.
- Light to moderate field operations—cultivation, tillage, seeding.
- Towing trailers or transport between fields, especially with road speed up to 40 km/h.
- Mixed-farm / utility roles where versatility and reliability are more important than absolute horsepower.
Pre-Purchase / Inspection Checklist.
2010 Claas Arion 610 C – Strong 4WD
- Check engine hours and service history; ensure regular oil / filter changes and cooling system maintained.
- Test transmission: Powershift and shuttle behaviour under load must be smooth, no slipping or harsh shifting.
- Hydraulic system: lift arms, remotes, hoses; check pump flow under load for any drop-off.
- PTO function: 540/1000 rpm engagement; check for clutch wear and sound under PTO load.
- Tire condition: matching front and rear; sidewall / tread wear; rims in good shape.
- Cab condition: comfort, visibility, controls, operator station (lights, seats, mirrors etc.).
- Check structural condition: chassis, hitch, front axle if used, drawbar etc.
- Verify all safety items: brakes, steering, lights, compliance with local road-worthy requirements if used on roads.
Product Summary Table.
2010 Claas Arion 610 C – Strong 4WD
| Feature | Specification / Value |
|---|---|
| Make / Model | Claas Arion 610 C |
| Gross Power | ≈ 123 HP (≈ 92 kW) |
| Net Power | ≈ 114 HP (≈ 85 kW) |
| Transmission | 16F × 16R Powershift / Shuttle |
| Operating Weight | ~5,720 kg |
| Transport Speed | ≈ 40 km/h |
| Hydraulic Flow | ≈ 110.1 L/min |
| Rear PTO Speeds | 540 / 1000 rpm |
| Tire Sizes (Typical) | Front 14.9R28; Rear 18.4R38 |
| Fuel Capacity | ~280 L |
Conclusion – Solid Mid-Range Tractor for Versatile Farmers.
2010 Claas Arion 610 C – Strong 4WD
If you’re after a tractor in the 120-HP class with good build, dependable hydraulics, and enough power for loader, PTO and field work, the **Claas Arion 610 C** is a strong candidate. Prioritize units with good maintenance, clean hydraulic & PTO function, decent tires, and a smooth powershift transmission. For many operations, this model offers excellent value without the high costs of larger machines. Order Here.
